3 in. 1.5 Ton Painted Snatch Block
The 3 in. 1.5 Ton Painted Snatch Block is a versatile and durable tool designed to assist in lifting and rigging tasks. With its robust construction and thoughtfully engineered features, this snatch block is built to withstand demanding work environments and deliver reliable performance.
This snatch block features a sturdy steel construction that is finished with a powder-coated paint, providing excellent durability and corrosion resistance. Its 3-inch sheave is factory-mounted, ensuring smooth movement and minimizing friction during cable operation. The sheave can accommodate boat lift cables up to 1/2 inches in diameter, providing flexibility in cable selection.
To ensure secure attachment and easy detachment, the snatch block is equipped with a break-away shackle. The shackle, with its bow-shaped design, offers a reliable connection point for the cable. The snatch block also features ears that support the shackle pin, enhancing stability and load distribution.
Maintenance is made convenient with the inclusion of a cast protected 1/4 inch grease fitting. This grease fitting allows for easy lubrication of moving parts, ensuring smooth operation and reducing wear and tear. The housing of the snatch block is designed to hold the 3-inch sheave and is equipped with a 1/4 inch grease fitting as well as a bottom bolt, both of which are cast protected for added durability.
With dimensions of 6 1/2 inches x 3 7/8 inches x 3 inches, this snatch block strikes a balance between compactness and functionality. Each snatch block weighs approximately 3 1/2 pounds, making it lightweight and portable while still maintaining strength.
The 3 in. 1.5 Ton Painted Snatch Block is a reliable and efficient tool for light-duty lifting and rigging applications. Whether you’re involved in marine operations, construction projects, or general lifting tasks, this snatch block is designed to meet your needs. Its high load capacity, compatibility with various cable sizes, and user-friendly features make it an indispensable component of any lifting and rigging toolkit.
Please note that when using this snatch block, it is crucial to ensure that the selected shackle meets or exceeds the working load limit (WLL) for your specific application. Always prioritize safety and follow industry best practices to ensure proper and secure operation.
Choose the 3 in. 1.5 Ton Painted Snatch Block for its durability, versatility, and performance, and experience enhanced efficiency and safety in your lifting and rigging operations.
|Sheave Size||3 in. x 3/4 in.||Sheave Bore||1/2 in.|
|Sheave Cable Groove||1/2 in.||Shackle Dimensions||3 in. x 3 in. x 5/8 in.|
|Safety Pin Holes||2||Safety Pin Hole Size||1/2 in.|
|Safety Pin Quick Release Size||2 7/8 in. x 5/16 in. (Fully Extended)||Yarding Block Dimensions||4 3/4 in. x 3 7/8 in. x 3 1/4 in.|
|Grease Fitting Size||1/4 in. (Cast Protected)||Housing Bottom Bolt||1 3/4 in. x 1/4 in. (Cast Protected)|
|Weight||3 1/2 lbs. (each)||Material||Steel|
|Finished||Galvanized||Stamp Rating||1.5 ton / 3,000 lbs.|
|Dimensions||6 1/2 in. x 3 7/8 in. x 3 in.|
- 3 in. sheave
- 1.5-ton capacity
- Corrosion-resistant steel
- Break-away shackle
- Accepts 1/2 in. cable
- Easy installation
