Lil Lifter Sheave Brackets
Lil Lifter Sheave Bracket FLAT
The Lil Lifter Sheave Bracket FLAT is a precision-machined, all-aluminum plate designed for use with the manual 1200 lb Lil Lifter. This part serves as the front housing plate for the upper sheave and is identified in the instructions as part 8 under Detail B. It is expertly drilled and machined for a perfect fit.
This bracket is sold as a standalone piece and does not include bolts. It pairs seamlessly with the Top Sheave Bracket BENT (Item BH09340). Please note that the sheave is not included.
Lil Lifter Sheave Bracket BENT
The Lil Lifter Sheave Bracket BENT is crafted from high-quality, machined aluminum, designed for the manual 1200 lb Lil Lifter. This bracket functions as the back housing plate for the upper sheave and is identified in the instructions as part 9 under Detail B.
Like its counterpart, this bracket is expertly drilled and machined for a precise fit. Sold as a standalone piece, it does not include bolts. It pairs perfectly with the Top Sheave Bracket FLAT (Item BH09341). Please note that the sheave is not included.
Specifications
| Feature | Top Sheave Bracket FLAT (Item BH09341) | Top Sheave Bracket BENT (Item BH09340) |
|---|---|---|
| UPC | 658580093419 | 658580093402 |
| Weight | 0.2 lbs | 0.2 lbs |
| Dimensions | 7 1/8″ x 2 1/2″ x 1/8″ | 7 1/8″ x 2 1/2″ x 3/4″ |
| Material | Machined aluminum | Machined aluminum |
| Purpose | Front housing plate for the upper sheave | Back housing plate for the upper sheave |
| Instruction Reference | Identified as part 8 in Detail B | Identified as part 9 in Detail B |
| Compatibility | Pairs with Item BH09340 | Pairs with Item BH09341 |
| Bolts Included | No | No |
| Sheave Included | No | No |
Product Overview
- Lightweight, durable aluminum design
- Precisely machined and drilled
- Fits manual 1200 lb Lil Lifter
- Front and back plate options
- Bolts and sheave excluded
- Pairs for seamless assembly
