1 HP Elite TENV Stainless Bremas Wired PWC Motor
The 1 HP Elite TENV Stainless Bremas Wired PWC Motor, a versatile electric motor pre-wired with a Bremas rotary cam momentary switch, an inline GFCI, and a 6 ft. cord from GFCI to plug. This motor is specifically designed for use with the BH-360 PWC Lift, Coastal Series PWC Skiff Lift, or other PWC hoists requiring an electric motor with a 56c input type.
This single-phase, dual-voltage motor operates at 110V and is constructed from robust rolled steel. The NEMA 56 shaft, measuring 0.625 inches in thickness and extending 1.88 inches from the motor housing, ensures reliable performance. With UL Recognized (C-UL-US) certification and a capacitor for a smooth start, this motor guarantees efficiency and durability.
The motor weighs 28.60 lbs. and comes in an individual box measuring 15 in. x 10 in. x 10 in. Its product dimensions are 10.75 in. (length) x 6.50 in. (width) x 9.0 in. (height), with a 0.625 in. shaft width and 2 in. shaft length. Originating from China, it is identified by the model number 93048 and retail SKU 93091.
This 1 HP motor operates on dual voltages (115v / 230v), with a single-phase configuration. It draws 15.6 Amps at 115V and 7.8 Amps at 230V. Operating at 1725 RPM and 60 Hz, the motor has a frame size of 56c, a service factor of 1.15, and is suitable for ambient temperatures up to 40°C. The motor is thermally protected, and its insulation is rated as F. It has UL Recognized status with the stamp C-UL-US.
Featuring a capacitor start and selective rotation, the motor has a NEMA 56 shaft type with an extension of 1.88 in. The frame length is 9.0 in., and it is mounted on a round base. The drive end and opposite drive end bearings are ball-type, and the frame material is stainless steel. The motor comes with a replacement capacitor (800 uF), included key stock (1 in. length, 0.25 in. width).
General Specifications for Momentary Switch
The momentary switch (model #: CA0200034I-B96IQ6R) is designed for ease of use. It weighs 1.25 lbs. and features a light grey housing measuring 4.5 in. (length) x 3.5 in. (width) x 4.5 in. (height). The red handle is 3 in. long, 1.1875 in. wide, and 1.3125 in. high. The switch is made in Italy, and its BH-USA SKU is BH09015.
Technical Specifications for Momentary Switch
The momentary switch has a rating of 20 Amps at 600 VAC with tight torque. It is certified according to EN 60947-3, CE, and C-UL-US Listed.
GFCI Wire Harness Specifications for 110v
The 110v wire harness, manufactured by Southwire Company, features a 3-US 110 V Standard plug type. Operating at 125 VAC, 60 Hz, and 15 Amps, this in-line GFCI has rainproof Class A characteristics. The cable type is 14/5 SJTW, with a GFCI to plug length of 4.5 in. The cord diameter range is 0.28 in. – 0.65 in. Listed by UL, certified by CSA, it includes an automatic reset button. The BH-USA SKU is 12211, and the catalog number is 303385214.
With these top-tier specifications, the 1 HP Elite TENV Stainless Bremas Wired PWC Motor is your ideal choice for powering PWC lifts and hoists, ensuring a reliable and efficient operation.
Totally Enclosed Non-Ventilated (TENV)
A Totally Enclosed Non-Ventilated motor is a type of electric motor that is enclosed to prevent the ingress of foreign particles (dust, moisture, etc.) but does not have external ventilation openings for air circulation. Unlike some other motor types, TENV motors do not rely on external airflow for cooling and are designed to operate in a sealed environment.
|Weight:||28.60 lbs.||Individual Box Size:||15 in. x 10 in. x 10 in.|
|Product Length:||10.75 in.||Product Width:||6.50 in.|
|Product Height:||9.0 in.||Shaft Width:||0.625 in.|
|Shaft Length:||2 in.||Country of Origin:||China|
|Model #:||93048||Retail SKU:||93091|
|HP:||1||Voltage:||Dual (115v / 230v)|
|Phase:||1||Amps:||15.6 (115v) / 7.8 (230v)|
|SFA:||17.5 (115v) / 8.75 (230v)||Type:||C|
|Electrical Type:||Capcitor Start||Rotation:||Selective|
|Shaft Type:||NEMA 56||Shaft Extension:||1.88 in.|
|Frame Length:||9.0 in.||Mounting:||Round|
|Drive End Bearing:||Ball||Opp Drive End Bearing:||Ball|
|Frame Material:||Stainless Steel||Replacement Capacitor:||800 uF|
|Capacitor SKU #:||BH02246||Keystock:||Included|
|Keystock Length:||1 in.||Keystock Width:||0.25 in.|
|Model #:||CA0200034I-B96IQ6R||BH-USA SKU #:||BH09015|
|Housing Length:||4.5 in.||Handle Length:||3 in.|
|Housing Width:||3.5 in.||Handle Width:||1.1875 in.|
|Housing Height:||4.5 in.||Handle Height:||1.3125 in.|
|Box Color:||Light Grey||Handle Color:||Red|
|Country of Origin:||Italy||Weight:||1.25 lbs.|
GFCI Wire Harness Specifications
|Manufacturer:||Southwire Company||GFCI to Plug:||4.5 in.|
|Plug Type:||3-US 110 V Standard||Cord Dia. Range:||0.28 in. – 0.65 in.|
|VAC:||125||Country of Origin:||Honduras|
|Type:||Rainproof Class A||Reset Type:||Automatic|
|GFCI Type:||In-line||BH-USA SKU:||12211|
|Cable Type:||14/5 SJTW||Catalog #:||303385214|
- 1 HP Elite PWC Motor for hoists
- Single-phase, dual-voltage with 110V operation
- Rolled steel construction, durable and robust
- NEMA 56 shaft, 0.625 inches thick
- UL Recognized, C-UL-US certified for safety
- Capacitor start for smooth operation
- Momentary switch for user convenience
- Stainless steel frame for added durability
- 6ft. In-line GFCI with automatic reset button
- Versatile motor suitable for outdoor use
