1 HP Elite TENV Stainless Electric Motor With Base

$ 363.69
SKU: 97211
UPC: 658580972110


Free Shipping

Free Shipping

BH-USA offers free shipping for retail customers on select items. Products eligible for free shipping will be shipped via UPS Ground. We offer expedited services for those individuals that require a more time-sensitive delivery time. If you add any items that are not free shipping, the cart will calculate and display a shipping price based on ONLY the items that are not free shipping. Whenever free shipping is available, it will appear above the "Add to Cart" button on the product page.


1 HP Elite TENV Stainless Electric Motor With Base

The 1 HP Elite TENV Stainless Electric Motor With Base is a single-phase, dual-voltage boat lift motor. The welded base of the motor is compatible with standard mounting patterns found on flat-plate gear plates, which are commonly used in boat hoists to lift and lower boats.  The Elite Motor has a marine grade stainless steel housing and features aluminum end plates that resist corrosion and rust. The heavy marine-grade gasket on the stainless steel capacitor housing helps keep water and dust out. Easy to wire with standard yellow T-Wires and works with any known drum switch or boat lift remote.

This motor will work on all flat-plate hoist brands including:  Boat Hoist USA, ACE Labs, American Power Hoist, AMS, and Hefty Hoist. It comes with detailed wiring instructions for wiring too Breams and Salzer drum switches, ensuring easy installation.  Additionally, it is fully compatible with remote controls from GEM, Galaxy, TEC, and Elite for convenient and efficient boat lift operation.  This motor is equivalent to the Leeson boat hoist motor #6439191252.

The motor has a power rating of 1 horsepower (HP) and can run on either 115 volts or 230 volts. When operating at 115 volts, it draws 15.6 amps, and at 230 volts, it draws 7.8 amps. It spins at a speed of 1725 revolutions per minute (RPM) with a frequency of 60 Hz.  It is a 56 frame mount and has a service factor of 1.15. . It can operate at an ambient temperature of up to 40°C for a maximum of 15 minutes. The housing is Totally Enclosed Non-Ventilated (TENV). It has insulation class F and is UL-recognized with a C-UL-US stamp.

Totally Enclosed Non-Ventilated (TENV)

A Totally Enclosed Non-Ventilated motor is a type of electric motor that is enclosed to prevent the ingress of foreign particles (dust, moisture, etc.) but does not have external ventilation openings for air circulation. Unlike some other motor types, TENV motors do not rely on external airflow for cooling and are designed to operate in a sealed environment.

When wiring or rewiring electrical components, BH-USA recommends hiring a licensed electrician.

General Specifications

Weight: 29.80 lbs. Individual Box Size: 15 in. x 10 in. x 10 in.
Product Length: 10.75 in. Product Width: 6.50 in.
Product Height: 10.0 in. Shaft Width: 0.625 in.
Shaft Length: 2 in. Country of Origin: China
Model #: 93048 Bulk SKU: 62544

Nameplate Specifications

HP: 1 Voltage: Dual (115v / 230v)
Phase: 1 Amps: 15.6 (115v) / 7.8 (230v)
RPM: 1725 Hz: 60
Frame: 56c Service Factor: 1.15
SFA: 17.5 (115v) / 8.75 (230v) Type: C
AMB: 40°c Time: 15 MIN
Insulation: F Thermally Protected: None
UL: Recognized UL Stamp: C-UL-US

Technical Specifications

Electrical Type: Capacitor Start Rotation: Selective
Shaft Type: NEMA 56 Shaft Extension: 1.88 in.
Frame Length: 9.0 in. IP Rating: IP55
Drive End Bearing: Ball Opp Drive End Bearing: Ball
Frame Material: Stainless Steel Replacement Capacitor: 800 uF
Capacitor SKU #: BH02246 Key stock: Included
Key stock Length: 1 5/16 in. Key stock Width: 3/16 in.

Product Overview

  • IP55 rating
  • Features both a 56C and 56F base
  • Stainless steel construction for corrosion resistance
  • Dual-voltage flexibility with adjustable T-Wires
  • Robust NEMA 56 shaft for stability
  • UL Recognized for safety assurance
  • Compact and secure packaging for shipping
  • High-performance 1 HP output
  • Versatile NEMA 56C frame category
